DL1315HK Compact Strand Steel Wire Rope for Truck Crane

DL1315HK Compact Strand Steel Wire Rope for Truck Crane

Description:

1. Common structure: DL1315HK

2. Surface treatment: galvanized, bright, oiled, etc. (as requirements)

3. Material: carbon steel, etc.

4. Diameter：Customized according to customer needs.

5. Breaking load：Customized according to customer needs.

6. Application: hoisting, electric power engineering, truck crane, etc.

Certificate & Standard:

Certificate：ABS，LR，CE，CCS，BV，DNV

Standard：GB8919，GB/T 20067, ISO, ASTM, EN, JIS, etc.

Drawing of the DL1315HK compact strand steel wire rope for truck crane：

Parameter of DL1315HK compact strand steel wire rope for truck crane:

DL1315HK compact strand steel wire rope for truck carne
Nominal rope diameter		Approx weight (kg/100m)	Rope grade /(MPa)
D	Tolerance (%)		1670	1770	1870	1960
(mm)			Minimum breaking load(kN)
12	+4 -1	69.1	106	112	118	124
13		81.1	124	132	139	146
14		94.1	144	153	161	169
15		108	165	175	185	194
16		123	188	199	211	221
17		139	212	225	238	249
18		156	238	252	267	279
19		173	265	281	297	311
20		192	294	312	329	345
21		212	324	343	363	380
22		232	356	377	398	417
23		254	389	412	435	456
24		276	423	449	474	497 539
25		300	459	487	514
26		324	497	526	556	583
27		350	536	568	600	629
28		376	576	611	645	676
29		404	618	655	692	725
30		432	661	701	741	776
32		492	752	797	843	883
34		555	849	900	951	997
36		622	952	1009	1066	1118
38		693	1061	1125	1188	1245
40		768	1176	1246	1316	1380
