DN1100 Dredge Gate Valve

DN1100 Gate Valve

Application
The DN1100 dredge gate valve is widely used for dredge pipe line,the product is to open and close pipe lines for slurry transportation on dredge vessels or ships.The DN1100 dredge gate valve is an essential component in dredging operations, allowing operators to control the flow of materials through the pipeline. Its sturdy construction and adjustable gate mechanism provide reliable and precise control, contributing to efficient and effective dredging processes.
Advantages
1.Long service life
2.Simple structure,high quality.
3.Professional pre-sale and after-sale.

Material
1.Seal:NBR,NR.
2.Valve body:Q235,16Mn.
2.Valve gate:stainless steel.
3.Hydraulic cylinder:body steel45,pistion rod 1Cr17Ni2.

Technical Parameters

1.Working Pressure PN≤1.6Mpa
DN	H1(mm)	H2(mm)	b(mm)	d(mm)	K(mm)	D(mm)	n-Th
1100	785	4280	1350	436	1270	1340	32-M33
we can modify the parameters,according to your requirements.

2.Working Pressure PN≤2.5Mpa
DN	H1(mm)	H2(mm)	b(mm)	d(mm)	K(mm)	D(mm)	n-Th
1100	830	4380	1350	748	1320	1415	32-M42
we can modify the parameters,according to your requirements.
