EU Type Bulwark Mounted Chock

EU Type Bulwark Mounted Chock

Description:

WWhen we are talking about chocks, there are always two types, deck mounted chock and bulwark mounted chock according to different application position on ships. EU type chock have two types based on their installation, they are EU type deck mounted chock and EU type bulwark mounted chock. If you are interested in any of our products, please feel free to contact us.

Drawing of EU Type Bulwark Mounted Chock:

Parameters of EU Type Bulwark Mounted Chock:

Nominal Size A x B (mm)	Dimension(mm)									Weight
	A	B	C	D	E	H	K	L	N	(kg)
315x250	315	250	695	630	432	342	22	168	497	198
425x280	425	280	925	780	516	450	26	224	661	358
600x315	600	315	1160	875	571	504	30	250	866	547
600x450	600	450	1160	1010	706	504	30	250	866	629

Features:

Model Type: Bulwark Mounted Chock;

Material: Cast Steel;

Certificates: CCS, ABS, BV, LR, NK, RINA, etc..

Display of Other Types of Bulwark Mounted Chock:
