GB T598 Marine Bronze Male Thread Cock

GB T598 Marine Bronze Male Thread Cock

1. Application

GB T598 Marine Bronze Male Thread Cock can be used in sea water, fresh water, lubricanting oil and fuel oil.

2. Material

body & core: cast tin bronze

The materials mentioned before are basic materials, ship-owners can choose better materials.

3. Nominal Pressure(KPa) & Diameter(mm)

Pressure: 1.0 ; 1.6 ; 2.5

Diameter: 32 ; 20, 25 ; 6, 10, 15.

4. Features

(1) We can according to customer demand for customized the material.

(2) We have IACS Certificate such as CCS, ABS, LR etc.

5. Dimensions

DN (mm)	Structure dimension			Thread joint				Handle L0	Weight(kg)
	L	H1	H	D	D1	D2	I		A	T	L
6	70	20	60	M22*1.5	-	-	12	100	0.42	0.48	0.49
10	78	27	72	M27*1.5	-	-	15	110	0.69	0.71	0.72
15	92	37	92	M36*2	-	-	16	115	1.07	1.24	1.26
20	98	40	99	M36*2	33	24	20	125	1.52	1.70	1.72
25	106	42	108	M42*2	39	29	20	140	1.90	2.22	2.24
32	126	49	120	M48*2	45	36	20	160	3.47	3.79	3.89

6. IACS Certificate: DNV, BV, CCS, ABS, LR, NK, KR,RINA.
