Home > Fire Fighting System

Horizontal Fire Foam Bladder Tank

Horizontal Fire Foam Bladder Tank

Description:

Horizontal fire foam bladder tank consists of horizontal foam tank, bladder, proportional mixer, inlet pipe, safety valve, control valve and some auxiliary components. When the pressurized water flows through the proportional mixer, the proportional mixer will split the flow proportionally. A small portion of the water enters the interlayer of the liquid foam storage tank. The tank has a bladder, and the water will squeeze the bladder. After squeezing, the water is mixed automatically with foam extinguishing agent at a rate of 6% or 3%.

Product Detail:

Working pressure: 0.6-1.2 (MPa)

Flow: 10~96 (L/S)

Mixing ratio: 3%－6%

Pipe diameter of inlet and outlet: DN100-DN250

Photo 1 of Horizontal Fire Foam Bladder Tank:

Photo 2 of Horizontal Fire Foam Bladder Tank:
