JIS F7209 Simplex Oil Filter

JIS F7209 Simplex Oil Filter

1. Application

Its function is to continuously filter the solid impurities in the system at work, maintain the cleanliness of the system medium, reduce the failure rate of the system components, and extend the service life of the system media and equipment.

2.Material

(1). - Body: cast iron
(2). - Cover: cast iron
(3). - Filter cylinder: steel / stainless steel
(4). - Strainer handle: steel / stainless steel
(5). - Cover yoke: ductile iron / steel
(6). - Yoke bolt: steel
(7). - Drain plug: brass
(8). - Handle of cover: steel
(9). - Magnet: -
(10). - O-ring: rubber
(11). - Wire gauze: stainless steel
3. Features
(1). IACS Certificate: CCS,ABS,BV,LR,RINA.etc. are available.
(2). Manufactured according to JIS F7400 standards. The valve material can be chosen by customers.

4. Size Table(S type)

DN	d	L	D	C	NO.	h	t	H
5K20	25	190	85	65	4	12	14	240
5K25	25	190	95	75	4	12	14	240
10K25	25	190	125	90	4	19	18	240
5K32	32	260	115	90	4	15	16	328
10K32	32	260	135	100	4	19	20	328
5K40	40	260	120	95	4	15	16	328
10K40	40	260	140	105	4	19	20	328
5K50	50	280	130	105	4	15	16	405
10K50	50	280	155	120	4	19	20	405
5K65	65	340	155	130	4	15	18	495
10K65	65	340	175	140	4	19	22	495
5K80	80	370	180	145	4	19	18	525
10K80	80	370	185	150	8	19	22	525
5K100	100	420	200	165	8	19	20	651
10K100	100	420	210	175	8	19	24	651

5. IACS Certificate: RINA, BV, ABS, CCS, LR.
