JIS F7318 Marine Cast Steel Angle Globe Valve
JIS F7318 Marine Cast Steel Angle Globe Valve
1. Application
The products are used for controlling the medium to open and close ,preventing refluence in fuel oil piping, lubricating piping. Dimensions of flange are according to JIS B2220 flange dimensions of steel pipe.
2. Material
(1) . - Body: cast steel
(2) . - Seat: stainless steel
(3) . - Disc: stainless steel
(4) . - Stem: stainless steela
3. Nominal Diameter ＆ Pressure
Diameter: ND32~ND150
Pressure: 40K
4. Features
(1). We provide OEM service, accept customer label, develop the product with your drawings or samples
(2). Various style for each products and completely series pneumatic products for you to choose from
(3). Sample order and small quantity order are ok
5.Main Size List
|
IMPA Code |
Model
|
L |
D
|
C
|
No. |
h |
t |
H |
D2 |
|
750481 |
7318 40K032 |
114 |
229 |
140 |
105 |
4 |
19 |
350 |
200 |
|
750482 |
7318 40K040 |
121 |
241 |
160 |
120 |
4 |
23 |
370 |
200 |
|
750483 |
7318 40K050 |
146 |
292 |
165 |
13 |
8 |
19 |
405 |
224 |
|
750484 |
7318 40K065 |
165 |
330 |
200 |
160 |
8 |
23 |
455 |
250 |
|
750485 |
7318 40K080 |
178 |
356 |
210 |
170 |
8 |
23 |
500 |
315 |
|
750486 |
7318 40K100 |
216 |
432 |
250 |
205 |
8 |
25 |
590 |
400 |
|
750487 |
7318 40K125 |
254 |
508 |
300 |
250 |
8 |
27 |
660 |
450 |
|
750488 |
7318 40K150 |
279 |
559 |
355 |
295 |
12 |
33 |
740 |
500 |
6. IACS Certificate: CCS, ABS, BV, LR, RINA
