JIS F7330 Marine Forged Steel Angle Globe Valve

JIS F7330 Forged Steel Angle Globe Valve

1. Application

The products are used for controlling the medium to open and close ,preventing refluence in fuel oil piping, lubricating piping. Dimensions of flange are according to JIS B2220 flange dimensions of steel pipe.

2. Material

(1) - Body: forged steel

(2) - Disc: stainless steel

(3) - Stem: stainless steel

3. Nominal Diameter ＆ Pressure

Diameter:Type “S”:6 and 10

Type “F”:15 to 25

Pressure: 40K

4. Features

(1). Excellent quality control is one of our main principles.

(2). Various style for each products and completely series pneumatic products for you to choose from.

(3). OEM, ODM service is acceptable.Customer's special requirements will be satisfied in our factory.

5. Main Size List


IMPA Code

Size

L

L1

L2

L3

K

D

C

n

h

t

H

B2

D3

Type

“S”

750671

6

-

51

38

51

12

-

-

-

-

-

136

30

M20×1.5

750672

10

-

51

45

58

16

-

-

-

-

-

136

41

M24×2

Type

“F”

750676

15

-

90

-

-

-

115

80

4

19

20

185

-

-

750677

20

-

95

-

-

-

120

85

4

19

20

204

-

-

750678

25

-

100

-

-

-

130

95

4

19

22

224

-

-

JIS F7330 Marine Forged Steel Angle Globe Valve

6. IACS Certificate: BV, ABS, LR, CCS, RINA.
