Seawater Desalination Device

Seawater Desalination Device
1. Seawater Desalination Device Introduction
As the content of salt in the seawater is too high, that can not be used directly, there are mainly two methods to desalinate seawater, distillation and reverse osmosis. Distillation is mainly used for super‐huge type seawater desalination and heat energy rich area, energy consumption is very high. Reverse Osmosis is very widely applicable, low energy consumption and high desalination rate, so it‘s widely used.
We use the international best quality of seawater RO membrane. The membrane‘s salt removing rate is very high, with stable performance, safe and reliable. The HP pump we used is the international brand which is specialized in seawater desalination, with high and low pressure protection device, ensure the safety and reliable of the equipment. The treated water quality meets the national life drinking water quality standards (GB5749‐85), do not add any chemicals, can be used for direct drinking, fresh and sweet.
For the portable use, reliable water, cheap price etc., after a long time of design and practice, we integrate the reliable technology and advanced technology, make our equipment stand out.
2. Seawater Desalination Device Characteristics
(1) Auto operating by pressing one key and auto flushing, easy and convenient to operate. Touch screen + PLC automatic control, more integrated and convenient, real‐time running process, more vivid and visualized. Auto dosing, reducing the fouling of the seawater RO membrane.
(2) The machine sets up high and low voltage protection to prevent the machine from break downing. Device fault alarm and indication is convenient for identifying the causes and maintenance quickly. Kinds of flow and pressure testing instruments, monitoring the device operating state at any time.
(3) Online conductivity meter, monitoring the output water quality at any time. Fully polished stainless steel frame, safe and fastness, elegant appearance. USA imported DOW brand seawater RO membrane, max salt removing rate can reach up to 99.7%. High quality quartz sand filter, can remove the large impurities, alga and so on, and can be manual cleaning independently.
(4) All of the high pressure fittings adopt SS316 material, safe and corrosion resistant. Low pressure fittings adopt high quality UVPC material. Customized end side port FRP membrane housing, simple connection, safe and reliable. SEKO dosing pump, accurate dosing, reducing the fouling of the seawater RO membrane. Metering pump with the power switch, convenient to start and stop. The power cord and dosing tank’s level signal lines use the navigation plug connection, convenient disassembly of metering pump.
(5) Cartridge filter protect RO membrane, prolong RO membrane's service life. High quality stainless steel raw water pump. Final production water of ultraviolet disinfection online to ensure the output water quality. High quality SS316L electric slowly open valve, slow opening and closing device high pressure. Universal wheel and adjusting legs make the machine move easier and portable, and is suitable for installation and use under more conditions.
(6) Our machine also has modern design and high integration, such as moveable design, easy to move and assemble. Our machine has most matching accessories, can directly use after connect with water and power, easy operation. This machine has a wide range of power supply, can be connected with common household AC power, gasoline/diesel generator, also can be connected with solar and wind etc.
3. Seawater Desalination Device Technical Parameters

HS‐SWRO‐10m³

Flow rate

10 m³/day

Recovery rate

30%

Applicable power

AC220V，50HZ

Rated power

4KW

Feedwater TDS

<38000ppm

freshwater TDS

<600ppm

Working pressure

<6Mpa

operating temperature

10‐45℃

Feedwater residual chlorine

<0.1ppm

Feedwater SDI

<5

Feedwater turbidity

<1NTU

Feedwater PH value

3‐10

Equipment specification

90X86X140(cm)

Equipment net weight

210‐280Kg

Packing specification（wooden box）

95X90X1600(cm)

Packing gross weight

260‐350Kg

4. Seawater Desalination Device Process Flow

5. Certificates of Seawater Desalination Device: ABS, BV, DNV.GL, KR, RINA, NK, LR and CCS approvable.
