Synthetic Resin Work Light

Synthetic Resin Work Light

The Scope of Application：

This series lights fit for the ships with water dripping, water spattering, water coagulating and weather place, such as oven cabin room, dry cabin, tunnel, pipeline and weather deck, the lampshade is bolt blocking device, and convenient to connect.

Products Characteristic：

The material is synthetic resin

Production Authentication:

Approved by the CCS

Approved by the authentication of CE

Adopt the Japanese standard JISF8414-2003

Specification:

code	type	Power	Voltage	lamp holder	Material	color	protection class	Weight
792053	DS7-1M	15W	24V	FE12,FE14	synthetic resin	transparent red green yellow blue	IP56	1.1kg
792054	DS7-1M	15W	24V	FB15	synthetic resin		IP56	1.1kg
792057	DS7-2M	60W	220V	FE26	synthetic resin		IP56	1.2kg
792058	DS7-2M	60W	220V	FB22	synthetic resin		IP56	1.2kg

Synthetic Resin Work Light DS7-1M:

Drawing of Synthetic Resin Work Light DS7-1M:
