Inverted Angles
Application:
The inverted angles are also known as “L shaped section steel”, “unequal leg and unequal thickness angles steel”. They are often used in vessels, suitable for both civil ships and warships. In daily life, the inverted angles also can be used for building, bridges, power transmission towers and etc. We are able to supply inverted angles made of high quality steel grades and steel materials. Shipbuilding inverted angles, galvanized inverted angles, stainless inverted angles are all available by us. Besides, we can also provide you complete selections of dimensions. The inverted angles are manufactured by Chinese top steel mills in line with GB/T 706-2008 or JIS G3192-2008. If you want to know more details about products or have any specific requirements about products, please no hesitation to contact us.
Features of Inverted Angles:
• In line with GB/T 706-2008 or JIS G3192-2008
• Multiple uses for shipbuilding, building structures, bridges, beams
• General materials offered: A, B, D, E, AH32, DH32, Q235
• Sufficient stock
• Professional working attitude and considerate service
Dimensions of GB/T 706-2008 Inverted Angles:
|
Type |
Sectional Dimension (mm) |
Sectional Area (cm2) |
Nominal Weight (kg/m) |
|||||
|
B |
b |
D |
d |
r |
r1 |
|||
|
L250×90×9×13 |
250 |
90 |
9 |
13 |
15 |
7.5 |
33.4 |
26.2 |
|
L250×90×10.5×15 |
10.5 |
15 |
38.5 |
30.3 |
||||
|
L250×90×11.5×16 |
11.5 |
16 |
41.7 |
32.7 |
||||
|
L300×100×10.5×15 |
300 |
100 |
10.5 |
15 |
45.3 |
35.6 |
||
|
L300×100×11.5×16 |
11.5 |
16 |
49.0 |
38.5 |
||||
|
L350×120×10.5×16 |
350 |
120 |
10.5 |
16 |
20 |
10 |
54.9 |
43.1 |
|
L350×120×11.5×18 |
11.5 |
18 |
60.4 |
47.4 |
||||
|
L400×120×11.5×23 |
400 |
120 |
11.5 |
23 |
71.6 |
56.2 |
||
|
L450×120×11.5×25 |
450 |
120 |
11.5 |
25 |
79.5 |
62.4 |
||
|
L500×120×12.5×33 |
500 |
120 |
12.5 |
33 |
98.6 |
77.4 |
||
|
L500×120×13.5×35 |
13.5 |
35 |
105.0 |
82.8 |
||||
Dimensions of JIS G3192-2008 Inverted Angles:
|
Type |
Nominal Weight M (kg/m) |
Sectional Area A (cm2)
|
Sectional Dimension |
|||||
|
H |
B |
t |
T |
R |
r |
|||
|
L200×90×9×12 |
22.0 |
28.1 |
200 |
90 |
9 |
12 |
15 |
7.5 |
|
L225×90×9×12 |
23.8 |
30.3 |
225 |
90 |
9 |
12 |
15 |
7.5 |
|
L250×90×9×13 |
26.2 |
33.4 |
250 |
90 |
9 |
13 |
15 |
7.5 |
|
L250×90×10.5×15 |
30.3 |
38.5 |
250 |
90 |
10.5 |
15 |
15 |
7.5 |
|
L250×90×11.5×16 |
32.7 |
41.7 |
250 |
90 |
11.5 |
16 |
15 |
7.5 |
|
L275×100×10.5×14 |
32.8 |
41.8 |
275 |
100 |
10.5 |
14 |
15 |
7.5 |
|
L300×100×10.5×15 |
35.6 |
45.3 |
300 |
100 |
10.5 |
15 |
15 |
7.5 |
|
L300×100×11.5×16 |
38.5 |
49.0 |
300 |
100 |
11.5 |
16 |
15 |
7.5 |
|
L325×120×10.5×14 |
39.3 |
50.1 |
325 |
120 |
10.5 |
14 |
20 |
10 |
|
L325×120×11.5×15 |
42.6 |
54.3 |
325 |
120 |
11.5 |
15 |
20 |
10 |
|
L350×120×10.5×16 |
43.1 |
54.9 |
350 |
120 |
10.5 |
16 |
20 |
10 |
|
L350×120×11.5×18 |
47.4 |
60.4 |
350 |
120 |
11.5 |
18 |
20 |
10 |
|
L375×120×10.5×18 |
46.9 |
59.7 |
375 |
120 |
10.5 |
18 |
20 |
10 |
|
L375×120×11.5×20 |
51.4 |
65.4 |
375 |
120 |
11.5 |
20 |
20 |
10 |
|
L400×120×11.5×23 |
56.2 |
71.6 |
400 |
120 |
11.5 |
23 |
20 |
10 |
|
L425×120×11.5×23 |
59.3 |
75.5 |
425 |
120 |
11.5 |
24 |
20 |
10 |
|
L450×120×11.5×25 |
62.4 |
79.5 |
450 |
120 |
11.5 |
25 |
20 |
10 |
|
L475×120×11.5×28 |
67.2 |
85.6 |
475 |
120 |
11.5 |
28 |
20 |
10 |
|
L475×120×12.5×30 |
72.4 |
92.2 |
475 |
120 |
12.5 |
30 |
20 |
10 |
|
L500×120×12.5×33 |
77.4 |
98.6 |
500 |
120 |
12.5 |
33 |
20 |
10 |
|
L500×120×13.5×35 |
82.8 |
105 |
500 |
120 |
13.5 |
35 |
20 |
10 |
Angle steel in factory:
