Bronze CBM Marine Valve
1. Application
CBM 1069-81 Bronze Globe Valve generally used in fresh water, lubricanting oil, fuel oil and steam with a temperature of less than 250 degrees. And its main function is to prevent the backflow of the medium, to prevent the pump and drive motor reversal, and the release of the container medium.
2. Features
(1) material: bronze
(2) nominal pressure: 0.5MPa
(3) nominal diameter: 15mm~65mm
The material and nominal diameter of this product can be chosen according to your needs.
3. Main Products
1)Thermostatic Stem Valve Group
2)CBM 1070-81 Bronze SDNR Valve
3)CBM 1075-81 Bronze Stop Valve
4)CBM 1077-81 Bronze Lift Check Valve
5)CBM 1078-81 Self Closing Draw Off Valve
6)CBM 1080-81 Bronze Packed Cock
7)CBM 1107-82 Marine Bronze Fire Valve
8)CBM 1109-82 Marine Bronze Hose Connection Valve
Please click here if you want to get more detailed information
4. Dimensions
DN
(mm)
Structure dimension
flange
L
H
D
C
g
h
t
A
B
A
B
15
100
55
100
146
80
60
48
12
9
20
110
60
112
160
85
65
52
10
25
120
65
125
175
95
75
62
32
140
80
136
199
115
90
72
15
12
40
160
85
165
225
120
95
78
50
210
100
288
358
130
105
88
14
65
250
115
310
392
155
130
112
5. IACS Certificate: DNV, KR, BV, CCS, NK, LR, ABS, RINA.
