JIS F7369 Marine Cast Iron Gate Valve
1. Application
The products are used for controlling the medium to open and close ,preventing refluence in fuel oil piping, lubricating piping. Dimensions of flange are according to JIS B2220 flange dimensions of steel pipe.
2. Material
(1) . - Body: cast iron
(2) . - Seat: bronze
(3) . - Disc: bronze
(4) . - Stem: brass
3. Nominal Diameter ＆ Pressure
Diameter: DN50~DN400
Pressure: 16K
4. Features
(1). We have nearly 10 years experiences on valves exporting.
(2). Excellent quality control is one of our main principles.
(3). Can be used with a variety of flange pipe standard and sealing surface pattern to meet the various engineering needs
and users' requirements.
5. Main Size List
|
IMPA Code |
Model |
L |
D
|
C
|
No. |
h |
t |
H |
D2 |
|
|
7369 16K050 |
210 |
155 |
120 |
8 |
19 |
20 |
300 |
140 |
|
|
7369 16K065 |
240 |
175 |
140 |
8 |
19 |
22 |
350 |
160 |
|
|
7369 16K080 |
260 |
200 |
160 |
8 |
23 |
24 |
400 |
180 |
|
|
7369 16K100 |
290 |
225 |
185 |
8 |
23 |
26 |
450 |
200 |
|
|
7369 16K125 |
310 |
270 |
225 |
8 |
25 |
26 |
520 |
250 |
|
|
7369 16K150 |
330 |
305 |
260 |
12 |
25 |
28 |
580 |
280 |
|
|
7369 16K200 |
370 |
350 |
305 |
12 |
25 |
30 |
700 |
355 |
|
|
7369 16K250 |
430 |
430 |
380 |
12 |
27 |
34 |
845 |
450 |
|
750841 |
7369 16K300 |
490 |
480 |
430 |
16 |
27 |
36 |
1010 |
500 |
|
750842 |
7369 16K350 |
540 |
540 |
480 |
16 |
33 |
38 |
1070 |
560 |
|
750843 |
7369 16K400 |
610 |
605 |
540 |
16 |
33 |
42 |
1160 |
630 |
6. IACS Certificate: RINA, ABS, CCS, BV, LR.
