CBM 1070-81 Bronze SDNR Valve
1. Application
CBM 1070-81 Bronze SDNR Valve can used in installations where internal or external corrosion is undersirable and heavy pattern for ship building industry.
2. Features
(1) material: bronze
(2) nominal pressure: 0.5MPa
(3) nominal diameter: 15mm~65mm
To meet the different needs of customers, the special materials can be customized according to one's request processing.
3. Dimensions
DN
(mm)
Structure dimension
flange
L
H
D
C
g
h
t
A
B
A
B
15
100
55
100
146
80
60
48
12
9
20
110
60
112
160
85
65
52
10
25
120
65
125
175
95
75
62
32
140
80
136
199
115
90
72
15
12
40
160
85
165
225
120
95
78
50
210
100
288
358
130
105
88
14
65
250
115
310
392
155
130
112
4. IACS Certificate: DNV, KR, BV, CCS, LR, NK, ABS, RINA.
