CBM 1057-81 Cast Steel Globe Valve
1. Application
CBM 1057-81 Cast Steel Globe Valve plays an important role in cutting and throttling the medium in the pipeline.
2. Material
(1) body & cover: ZG230-450
(2) disc: 25
(3) stem: 2Cr13
To meet the different needs of customers, the special materials can be customized according to one's request processing.
3. Technical Data
(1) nominal pressure(MPa): 4.0
(2) nominal diameter(mm): 32~100
4. Features
(1) Excellent quality and beautiful shape.
(2) Applicable to a variety of medium.
5. Dimensions
DN
(mm)
Structure dimension
flange
L
H
D
C
g
h
t
A
B
A
B
32
229
114
304
405
140
105
80
19
27
40
241
121
334
430
160
120
90
23
27
50
292
146
354
469
165
130
105
19
29
65
330
165
409
539
200
160
130
23
33
80
356
178
436
574
210
170
140
23
35
100
430
216
466
591
250
205
165
25
39
6. IACS Certificate: BV, RINA, KR, DNV, CCS, LR, ABS, NK.
