CBM 1092-81 Caet Steel Gate Valve
1. Application
CBM 1092-81 Caet Steel Gate Valve can be used to repair shps and shipbuilding.
2. Material
(1) body & bonnet & plate: ZG25
(2) stem: 2Cr13
(3) sealing ring: H2Cr13
Your special material requirement can be met, such as cast iron, stainless steel 304, stainless steel 316L etc.
3. Technical Data
(1) nominal pressure(MPa): 1.0, 0.5, 0.4, 0.2
(2) nominal diameter(mm): 50~500
4. Features
(1) Applicable to a variety of medium.
(2) Strict quality control to ensure product quality.
5. Dimensions
|
PN (MPa) |
DN (mm) |
Structure dimension |
flange |
|||||
|
L |
H |
D |
C |
g |
h |
t |
||
|
1.0 |
50 |
200 |
340 |
155 |
120 |
100 |
19 |
16 |
|
65 |
220 |
372 |
175 |
140 |
120 |
19 |
18 |
|
|
80 |
230 |
430 |
185 |
150 |
130 |
19 |
18 |
|
|
100 |
250 |
459 |
210 |
175 |
155 |
19 |
18 |
|
|
0.5 |
125 |
270 |
527 |
235 |
200 |
180 |
19 |
18 |
|
150 |
290 |
566 |
265 |
230 |
210 |
19 |
18 |
|
|
0.4 |
200 |
310 |
658 |
320 |
280 |
255 |
23 |
20 |
|
250 |
340 |
755 |
385 |
345 |
320 |
23 |
22 |
|
|
300 |
380 |
840 |
430 |
390 |
365 |
23 |
22 |
|
|
350 |
420 |
945 |
480 |
435 |
405 |
25 |
24 |
|
|
400 |
480 |
1045 |
540 |
495 |
465 |
25 |
24 |
|
|
0.2 |
450 |
510 |
1228 |
605 |
555 |
525 |
23 |
23 |
|
500 |
560 |
1315 |
655 |
605 |
575 |
23 |
23 |
|
