RSR-1600 capacitor discharge stud welder

RSR-1600 capacitor discharge stud welder

1. Application

RSR-1600 capacitor discharge stud welder is specially designed for cabinet, cabinet, shell, barrel, container, kitchen appliance, electric cabinet, electrical cabinet, home appliance, stainless steel products, metal products, ventilation ducts, signs and so on.

2. Welding Material
Welding materials are carbon steel, stainless steel, copper, aluminum and alloy materials.Horizontal welding, vertical welding, pitching welding, all-directional welding.The plate thickness ≥ 0.3mm thin plate, welding M3 mm-M12 mm stud, screws, insulation nails.
3. Features
- Small size, less weight, protable;
- Digital display charging voltage, working conditions;
- Easy control panel with all welding parameters are indicated;
- Continuous stepless regulation of charge voltage to ensure welding convenience, flexibility and solidity;
- Self-detection system to protect the welding machines' reliability;

4. Technical Data

Item	RSR-1600
Welding range	Ø3mm-Ø6mm
Energy stored	1600J
Charge voltage	36V-200V
Welding speed	10-30pcs/minute
In put power	110v/220v  50Hz
Input capacity	≤0.6KW
Dimension (L,W,H)	418mm×226mm×200mm
Weight	15kg

5. Standard Accessories

Standard Accessories of C D Stud Weld
No.	Accessories	Spec.	Qty.
1	Weld gun	YF-DH-12J	1pc
2	Weld cable	25mm²	3m
3	Earth cable	25mm²	3m
4	grips	Ø3 ,Ø4, Ø5,Ø6,Ø8,Ø10	6pcs
5	Earth clamp	N/A	1pc

6. Certificate
