Home > Shackle

Stainless Steel Flat Shackle

Stainless Steel Flat Shackle

Description:

The body of stainless steel flat shackle is made by stamping sheet metal. Therefore, it has low production cost and high production efficiency. Our company has two types of stainless steel for you to choose. They are 304 stainless steel and 316 stainless steel.

Product Superiority:

1. Light weight

2. High load bearing capacity

Product Detail (please refer to “Drawing of Stainless Steel Flat Shackle”):

Specification of dee type stainless steel flat shackle:

Size(M)	S	H	W	E	D
mm	mm	mm	mm	mm	mm
M4	1.5	17	10	6	9
M5	2	20	12	7	11
M6	3	24	15	8	12
M8	4	44	21	10	18

Specification of bow type stainless steel flat shackle:

Size(M)	S	H	E	F	D
mm	mm	mm	mm	mm	mm
M4	1.5	15	5	9	8
M5	2	17	7	11	10
M6	3	23	8	16	12
M8	4	31	8	23	16
M10	5	40	11	25	20
M12	6	50	14	28	24

Drawing of Stainless Steel Flat Shackle:

Picture of Stainless Steel Flat Shackle:
