Type 930 Sheet Tile

Type 930 Sheet Tile

Type 930 sheet tile product performance:

1. Corrosion resistance

It doesn’t react with acid, alkali, salt and other chemical components. During the long-term use of the process, there is no possibility of corrosion. The product can maintain excellent physical performance.

2. Weather resistance

Using high-quality PVC resin as the base material, adding UV absorbent, antioxidant, modifier and etc. to ensure the service life of the product.Even if long-term exposure to ultraviolet radiation, moisture, heat, cold and other natural environment, and it still can maintain its stability, to ensure long-term safe use of products.

3. Loading resistance

Using the industry's advanced two-layer technology, compared with the common single layer tile which has higher mechanical strength and physical properties, the national chemical testing center test showing: 1.2meter purlin spacing increased 1500N, but deflection less than 3%.

4. Fireproof performance

Model 930 sheet tile inspected by the national chemical testing center inspection, fire performance grade is difficult to burn B1, all stressed fire safety laws and regulations of the plant are applicable, for the national building materials promotion association recommended the use of safe, environmentally friendly roofing materials.

5. Thermal insulation performance

The thermal conductivity of 930 model tile is 0.22, equals about 1/3 of clay tile, 0.5mm thick color steel tile 1/2000, so do not add any thermal insulation cooling facilities, 930 steel tile thermal insulation performance can still reach the best, can fully meet the demand.

6. Sound insulation noise reduction

It can effectively block rain, wind and other natural factors noises.

Specification

Valid Width(mm)                         850					Application
Total Width of Tile Surface(mm)            930					Roof Boarding Wall Panel (Arched Roof)
Thickness(mm)	1.5	2.0	2.5	3.0
Plate Sealing Height(mm)                  16
