Marine Fixed Pitch Bow Thruster

Marine Fixed Pitch Bow Thruster

Application
A marine fixed pitch (FP) bow thruster is a type of propulsion system used in ships and boats to provide additional maneuverability and control. It consists of a propeller mounted in a tunnel at the bow of the vessel, perpendicular to the direction of travel, and is powered by an electric or hydraulic motor. Fixed pitch bow thrusters are controlled using a joystick or a computerized system, which allows for precise and smooth maneuvering of the vessel. They can also be integrated with other ship systems, such as GPS and autopilot, to provide seamless operation.

Fixed pitch bow thrusters are typically used in smaller vessels, such as pleasure craft and yachts, where moderate levels of thrust are required to maneuver in and out of harbors or tight spaces. They can provide excellent maneuverability in a variety of marine environments, allowing the vessel to move sideways, forwards, or backwards as required.

Features
1.Propeller type: fixed pitch propeller.
2.Propeller diameter: 350mm-2000mm.
3.Max Input power: 115-960Kw/102-952Hp.
4.Advantage: Simplify the operation of vessel, increase the flexibility of vessel.
5.Drive force: Hydraulic and electric motor, Diesel engine.
6.We can design and manufacture the product according to client's drawing or sample.

Technical Parameters

Type	Propeller Dia	Input power max		Input rpm	Frequency	Inner.Φ.mm	Length mm	MAX.thruster
	Φmm	Kw	Hp	rpm	Hz	mm	mm	KN
SCT25-FP	250	20	27	1470	50	260	250	3.5
		25	34	1750	60			4
SCT35-FP	350	36	49	1470	50	360	320	6
		39	53	1750	60			6.5
SCT40B-FP		36	49	1470	50	412	350	6
SCT40-FP	400	48	65					7.6
		52	71	1750	60			8.2
SCT45B-FP	450	48	65	1470	50	462	400	7.9
SCT45-FP		60	82					9.5
		65	88	1750	60			10.4
